Volvo S60 Excels in New IIHS Crash Test
In IIHS's Small Overlap Frontal Crash Test, 25 percent of a car's front end on the driver side strikes a 5-foot-tall rigid barrier at 40mph. A 50th percentile male Hybrid III dummy is belted in the driver seat. The test is designed to replicate what happens when the front corner of a car collides with another vehicle or an object like a tree or utility pole. Outside of some automakers' proving grounds, such a test isn't currently conducted anywhere else in the United States or Europe.
IIHS states: "Nearly every new car performs well in other frontal crash tests conducted by the Institute and the federal government, but we still see more than 10,000 deaths in frontal crashes each year," Institute President Adrian Lund says. "Small overlap crashes are a major source of these fatalities. This new test program is based on years of analyzing real-world frontal crashes and then replicating them in our crash test facility to determine how people are being seriously injured and how cars can be designed to protect them better. We think this is the next step in improving frontal crash protection."
Take a look at some of the actual crash test videos recorded during the IIHS New Small Overlap Frontal Crash Tests.
The S60 achieved an overall rating of Good and was one of only two vehicles tested to achieve this rating. Some excerpts from IIHS's Press Release include:
- The Acura TL and Volvo S60 earned good
ratings, while the Infiniti G earned an acceptable rating. The Acura
BMW 3 series, Lincoln MKZ and Volkswagen CC earned marginal ratings. The Mercedes-Benz C-Class, Lexus
IS 250/350, Audi A4 and Lexus ES 350 all earned poor ratings. All of these cars are 2012 models.
- Structurally, the Volvo S60 was best. With
only a few inches of intrusion, the occupant compartment looked much
same as it did in a moderate overlap test. Reinforcement of the S60's upper rails and a steel cross member below the
instrument panel helped to keep the safety cage intact. Volvo has performed similar small overlap tests as part of its vehicle
safety development process since the late 1980s, taking the results into account when designing new models.
- Survival space for the driver wasn't well
maintained in the Lexus IS crash test. The A-pillar bent and the
as the left front wheel and tire were forced rearward. The dummy's feet were entrapped by intruding structures. Results for
the Volvo S60 were very different. The S60's occupant compartment held up well, with only minor intrusion. Comparitively,
the Lexus IS had up to 10 times as much intrusion into the occupant compartment as the Volvo.
